DAC series hub bearing 2

Wheel Hub Bearings

The main function of hub bearing is to bear weight and provide accurate guidance for the rotation of the hub. It bears both axial load and radial load, and is a very important component. The traditional automobile wheel bearing is composed of two sets of tapered roller bearings or ball bearings. The installation, oiling, sealing and clearance adjustment of the bearings are carried out on the automobile production line. This structure makes it difficult to assemble in the automobile factory, with high cost and poor reliability. In addition, when the automobile is maintained at the maintenance point, the bearing needs to be cleaned, oiled and adjusted. Hub bearing unit is developed on the basis of standard angular contact ball bearing and tapered roller bearing. It combines two sets of bearings as a whole. It has the advantages of good assembly performance, can omit clearance adjustment, light weight, compact structure, large load capacity, can be filled with grease in advance for sealing bearings, can omit external hub seal and is free from maintenance. It has been widely used in cars, and has the trend of gradually expanding its application in trucks.

Product parameter

Bearing Number	JAPAN(KOYO)	GERMANY(FAG)	SWEDEN(SKF)	JAPAN(NSK)	Dimension(mm)
Bearing Number	JAPAN(KOYO)	GERMANY(FAG)	SWEDEN(SKF)	JAPAN(NSK)	d	D	B	C
DAC38650052/48					38	65	52	48
DAC38680037				38KWD02	38	68	37	37
DAC386939/34					38	69	39	34
DAC38700037		ZFRTBRGH0037	BAHB636193C		38	70	37	37
DAC38700038	DAC3870BWCS41		686908A	38BWD21CA53	38	70	38	38
DAC38700038	DAC3870DWCS41		686908A	38BWD21CA53	38	70	38	38
DAC38700040					38	70	40	40
DAC38710033/30	3871W-2CS70		FW135	38BWD09ACA12	38	71	33	30
DAC38710039		574795A	VKBA3929	30BWD22	38	71	39	39
DAC38720034	DAC3872ACS42		VKBA1381	38BWD04CA60	38	72	34	34
DAC38720036/33	DAC3872W8CS81			30BWD12	38	72	36	33
	DAC3872W-3
	DAC3872W-6
DAC38720236/33	DAC3872W-3CS72		FW128	38BWD12	38	72.02	36	33
	DAC3872W-8CS72		VKBA1191
	DAC3872-WCS81
DAC38720040	DAC3872W-10	575069B	FW102		38	72	40	40
	DAC3872B12RSCS42		FWB12
			VKBA1377
DAC38730040	DAC3973-1		VKBA3245	38BWD26E	38	73	40	40
	DAC38732B12RSCS53
	3873W-12RSC5
DAC38740036/33	DAC3874W-6	574795A	DAD3874368W	38BWD07-26G	38	74	36	33
	DAC387436		FW114,WB1144	38BWD15
	BWDS69		VKBA1341147	38BWD16A
			BAH0041	38BWD01A1ACA
			VKBA32011	38BWD24
				38BWD01ACA12
DAC38740236/33	DAC3874E-6CS84		BHAH-0041	38BWD01A1	38	74.02	36	33
DAC38740040				38BWD01	38	74	40	40
DAC38740050			FW116/FWB116	38BWD06DAC71	38	74	50	50
DAC38740450		559192		38BWD06DAC72	38	74.04	50	50
DAC38800036/33				38BWD18	38	80	36	33
DAC381700037			BAHB636193C	38BWD19	38.1	70	37	37
DAC39680037	DAC39680037	439622C	BA2B309692	39BWD03CA69	39	68	37	37
		803374	BAHB311315	JRM3939
		528810	BAFB447333BD	3968XD
		528820	VKBA575	39BWD02
		540733BA
DAC39680637		540733CA	BAHB311315AD		39	68.06	37	37
DAC39680737					39	68.07	37	37
DAC39680837				39BWD02J	39	68.08	37	37
DAC39720037	DAC3972AW4	542186A	BAHB311396B	39WD01L	39	72	37	37
	DAC3972D-2RS	544096	309639	39BWD01BCA81
		581169	BAH0036
		579794CA	BA2B309639BA
		524096	VKBA736
			VKBA3531
DAC39720637		542186CA			39	72.06	37	37
DAC39740034					39	74	34	34
DAC39740036/34			395418		39	74	36	34
DAC39740038					39	74	38	38
DAC39740039	BAHB636096A	579557	BAHB636096A	39BWD05	39	74	39	39
DAC39740039	BAHB636096A	581108CA	BAHB636096A	39BWD05	39	74	39	39
DAC39/41750037	DAC39/41750037	567447B	BAHB633815A		39/41	75	37	37
DAC39/41750037	DAC39/41750037	567447B	VKBA1355		39/41	75	37	37
DAC40680037					40	68	37	37
DAC40680042					40	68	42	42
DAC40700043	DAC407040W			AU0840\|(NTN)	40	70	43	43
DAC40720036					40	72	36	36
DAC40720036/33					40	72	36	33
DAC40720836		805800			40	72.08	36	36
DAC40720037	DAC4072	566719	BAHB311443B		40	72	37	37
		455608	FWB130/FW130
			VKBA1358/VKBA1491
DAC40720637					40	72.06	37	37
DAC40730055			BTH1024C		40	73	55	55
DAC40740036/34	DAC4074CWCS73		40BWD16		40	74	36	34
DAC40740036/34	DAC4074BW		40BWD16		40	74	36	34
DAC40740036			40BWD15A		40	74	36	36
DAC40740040	DAC407440	559493	FW102	40BWD06B	40	74	40	40
		801136	BAHB636060C
			BAH-0049
			VKBA1950
DAC7404840					40	74.048	40	40
DAC40740042	DAC4074W-3			40BWD12CA88	40	74	42	42
DAC40750037		559494	BAHB633966E		40	75	37	37
			BAH0086
			VKBA1480
DAC40760033/28		539166AB	474743		40	76	33	28
DAC40760041/38	DAC4076412RS	559226	FW124VK	40BWD05	40	76	41	38
DAC40760041/38	DAC4076412RS	559226	BA1480	40BWD05	40	76	41	38
DAC40800036/34	DAC4080MICS68M		BAHB636187	40BWD14	40	80	36	34
			CFW101BAH	40BWD07A
			B636187C/A
DAC408000302		523854	440320H		40	80	30.2	30.2
DAC40800031			BA2B445469BA		40	80	31	31
DAC408000381		534682B	443096B		40	80	38.1	38.1
DAC40800036					40	80	36	36
DAC40800037					40	80	37	37
DAC40800038					40	80	38	38
DAC40800040					40	80	40	40
DAC40800044					40	80	44	44
DAC40800045/44	DU4080				40	80	45	44
DAC40820040					40	82	40	40
DAC408402538					40	84.025	38	38
DAC40840034					40	84	34	34
DAC40840038					40	84	38	38
DAC40840040					40	84	40	40
DAC401080032/17			BA2B445533		40	108	32	17
DAC401080032/17			495333		40	108	32	17
DAC41680040/35				41KWD01G3CA54	41	68	40	35
DAC42720038	DU4272C			BAHB1866047A	42	72	38	38
DAC42720038/35			VKBA3235	42KWD02AG3CA123	42	72	38	35
DAC42750037	DAC4275BW2RS	533953	BA2B633457		42	75	37	37
	DAC4275	545495D	BAHB311424A
		521771	309245
			603694A
			633196
			BAH0059C
DAC42760033		555801		42BWD12	42	76	33	33
DAC42760037/35					42	76	37	35
DAC42760038/33					42	76	38	33
DAC42760038/35			FW119	42BWD06CS98	42	76	38	35
DAC42760038			VKBA1999		42	76	38	38
DAC42760039		579102A	FW115/FWB115		42	76	39	39
DAC42760040/37	DAC427640-2RSF	547059	909042	42BWD02	42	76	40	37
DAC42760040/37	DAC427640-2RSF	547059A	BA2B30976BA	42BWD02	42	76	40	37
DAC42770039					42	77	39	39
DAC42780038	DAC4278BA-2RS			42BWD09	42	78	38	38
DAC42780040					42	78	40	40
DAC42780041/38					42	78	41	38
DAC428000302			633188		42	80	30.2	30.2
DAC42800036/34	DAC4080MA		BAH0117	42BWD13	42	80	36	34
DAC42800037			BAHB633770	42BWD11CA56	42	80	37	37
DAC42800037			BAH0004	42BWD11CA56	42	80	37	37
DAC42800040					42	80	40	40
DAC42800042	DAC4280B-2RS		BA2B309609AD		42	80	42	42
DAC42800342		527243C	305988		42	80.03	42	42
		582226	309609AD
			BA2B309609AD
